Glazed / PET Film Coated MGO Waves Roof Tile Making Machine Roof Sheet Machine 6mm Thickness

China Glazed / PET Film Coated MGO Waves Roof Tile Making Machine Roof Sheet Machine 6mm Thickness supplier

Large Image :  Glazed / PET Film Coated MGO Waves Roof Tile Making Machine Roof Sheet Machine 6mm Thickness

Product Details:

Place of Origin: China
Brand Name: chuangxin
Certification: CE
Model Number: XD-A

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: L/C, T/T
Supply Ability: 50 Sets per year
Contact Now
Detailed Product Description
Product Name: Roof Tile Machine Raw Material: Mgo,mgcl,fiber Glass Mesh
Type: Free Standing

Glazed / PET Film Coated MGO Waves Roofing Tiles Roof Sheet Machine 3mm - 6mm Thickness



Product description



Mgo roof tile forming machine can produce glazed, or PET film coated MGO roofing tiles with all kinds of waves and heat-preserving layer, which will be used at the roof as the substitute of traditional asbestos tile, color steel tile and cement tile.

2. Machine Model:

According to different production capacity from 300 tiles to 900 tiles per eight

hours the tile-making machine has different models for large-scale, middle-scale and small-scale.

Equipment Model and Product Specification

According to different production, our equipment has 6 models for large-scale, middle-scale and small-scale. Our all equipment can produce board with same quality and specification but different production.

Customers can adjust the specification of the pantile according to different requirements, the standard specification is 1.8mX0.72m, the biggest length is 6 m, the thickness is 3mm~6mm generally. In addition, this equipment can produce the pantile with heat-preserving layer.

All machine can produce tile with same best-quality and specification board, only

has different production capacity.



3. Application of Roof Tile

The roof tile produced by our machine with all kinds of waves and heat-preserving

 layer, which will be used at the roof as the substitute of traditional asbestos tile,

color steel tile and cement tile. There is asbestos in the asbestos tile which include

 carcinogen.



4. Tile performance:

Performance

Standard

Test Value

Transverse breaking-resistance

7/3000N/M

4900 N/M

Vertical breaking-resistance

7/200 N/M

320N/M

Anti-impact force

No chap, peeling and crack

None

Water absorption

26%

14%

Imperviousness

No spot and water

drop on the back of pantile

after it was watering

None

Frost resistance

No phenomenon of layer-producing after 25

 times freezing-thawing

No phenomenon of

 layer-producing

Artifical chalking grade

None

None

Climate Aging Change Grade

≤2

None

Climate Aging Chromatism Grade

E≤3

0.66



  Glazed / PET Film Coated MGO Waves Roof Tile Making Machine Roof Sheet Machine 6mm ThicknessGlazed / PET Film Coated MGO Waves Roof Tile Making Machine Roof Sheet Machine 6mm Thickness

Mgo roof tile Machine
