Fireproof Calcium Silicate Board Production Machinery / Waterproof Fiber Cement Plate Line

Fireproof Calcium Silicate Board Production Machinery / Waterproof Fiber Cement Plate Line
Fireproof Calcium Silicate Board Production Machinery / Waterproof Fiber Cement Plate Line Fireproof Calcium Silicate Board Production Machinery / Waterproof Fiber Cement Plate Line Fireproof Calcium Silicate Board Production Machinery / Waterproof Fiber Cement Plate Line Fireproof Calcium Silicate Board Production Machinery / Waterproof Fiber Cement Plate Line

Large Image :  Fireproof Calcium Silicate Board Production Machinery / Waterproof Fiber Cement Plate Line

Product Details:
Place of Origin: CHINA
Brand Name: chuangxin
Certification: CE
Model Number: XD-1
Payment & Shipping Terms:
Minimum Order Quantity: 10 sets
Price: 30000USD
Packaging Details: wood packing
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 10 set per month

Fireproof Calcium Silicate Board Production Machinery / Waterproof Fiber Cement Plate Line

Description
Raw Materials: Fiber Glass Mesh Asbestos: 100%no Abestos
Fuel: Electric Brand Name: Shandong Chuangxin
Surface: Smooth
High Light:

fiber cement board machine

,

sheet forming machine

fireproof Calcium Silicate Board Production Machinery / waterproof Fiber Cement Plate Line





Production conditions



Required Raw Material:

fiber cement board is made of cement ,sand, or any kind of crop straw and inorganic material (such as talcum powder and powder coal ash) after special technology. So this project has low production cost, small investment and fast effectiveness.

Wall Board Performance.



1 Air-dry density ≤ (Standard index)50kg/m2 (Test Value) 30.0kg/ m2
2 Drying shrinkage rate of the board ≤0.08% 0.015%
3 Anti-breaking load ≥1400N 5640N
4 Anti-impact No breakage phenomenon such as cracking after three impacts No breakage phenomenon such as cracking after three impacts
5 Thermal resistance of main section (T=90mm) ≥1.35(m2.k)/w ≥1.36(m2.k)/w
6 Thermal bridges area ratio ≤8% 2.22%
7 Sound reduction Index   36dB
8 Radioactivity   None



No. Test items Standard indicators Test results
1 Bending degrees
Horizontal > =22Mpa 24.9Mpa Qualified
Vertical > =17 Mpa 21.4Mpa



2 Impact strength > =2.0 KJ/m2 3.7KJ/m2 Qualified



3 Indensity > =1.6g/cm3 1.72g/cm3 Qualified



4 Water absorption < =24% 16.8% Qualified



5 Waterproofness According to the National standard GB8041 tested -24H checking allow damp mark on the back of the board, but no water drop Meet the National standard GB8041 Qualified



6 Freezing resistance According to the National standard GB8041 tested- after 25 times Cycliccrackingno break and layer appear Meet the National standard GB804
High density 1.4≤ D≤ 1.7 ≤ 28

__

Compressive Strength ~20 MPa (3, 000 PSI)
Impact Resistance > 6 kJ/m2
Tensile Strength > 5.5 MPa
Density (Specific Mass) ~1000 Kg/m3 (+/-< 2%)
Moisture Absorption

~26% maximum saturation

(slow absorption rate)

Moisture Content ~6%
Water Vapour Diffusion ~28 / 35
Specific Heat ~930 J/kgK
Thermal Conductivity ~0.44 W / mK
Modulus of elasticity ~6045 N/mm2
Flexibility
UNI E 12372
~20.1 N/mm2 maximum
12mm x 1220 x 2440 = 10 N/mm2
Surface Alkalinity ~10 Ph
Thermal Expansion Hot/Cold 0, 01 mm/mC (from temp +20C to -20C)
Expansion in Water less than < 0.02% from ambient to saturation
Freeze / Thaw - UNI EN 520 100 cycles without notable effects
Frost Resistance no water drops form on surface
Combustibility / Fire Ratings

non-combustible / 12mm exceeds

1 hr fire rating

Dimensional tolerance

thick 0.2mm / width 2mm / length 3mm

/ Sq. 3mm

Toxicity Pollutants Heavy

Metals - UNI EN 12457-2

Below measurable levels of test instruments
Asbestos Analysis Absent - not measurable
Formaldehyde Analysis Absent - not measurable
Sound Attenuation (9mm) tested design ASTM E90 = STC 48, 50, 55, & 60
Color Slate Grey and Chalk White
Surface texture smooth one side; uniform machine textured back
Basic Compounds

(MgO)+(natural silicates)+(glass fibre)

+(wood fibre)



Advantages



1, Molding machine is specially designed and made to produce sandwich wall panel.



2, Reliabale mechanics performance: mechanics performance of the compound wallboards is all in the head of the wallboard include it's impact resist, perch up Strength, press, transverse resist.



3, The door frame board can or buried in advance directly because of improving the intensity of core bode, fix window frames of different types directly.



4, the product has sound insulation, fireproofing, and environmental protection.



Fireproof Calcium Silicate Board Production Machinery / Waterproof Fiber Cement Plate Line 0
