Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift
Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift
Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

Large Image :  Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

Product Details:
Place of Origin: CHINA
Brand Name: chuangxin
Certification: ce
Model Number: XD-D
Payment & Shipping Terms:
Minimum Order Quantity: 1 sets
Price: negotation
Packaging Details: packing
Delivery Time: 30 days
Supply Ability: 10 sets per month
Contact Now

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift

Description
Production Capacity: 2000sqm Type: Mgo Wall Panel Production Line
Usage: Making Mgo Wall Panels Performance: Water-proof,fire Resistent,sound-prevesion
Model Number: Design As Your Request After-sales Service: Engineers Available To Service Machinery Overseas
Highlight:

eps sandwich panel production line

,

roof panel roll forming machine



Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift



decorative magnesium oxide board production line capacity 2000 sheets / shift Mgo wall panel making machine

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift 0

Introduction of wall panel machine:

1. Metering System
After accurate weighing Fly ash, cement and sand, then being stirred with water into a slurry.
2. Forced mixing system
The slurry is transported by conveyor to the slurry compulsory mixer, and mixing with polystyrene particles evenly. Finally the slurry is poured into the mold.
3. Steam curing system.
The mould will be driven into curing room by the ferry cart for curing

 Raw material proportion

Name Ratio
Cement 50-70%
Flyash 20%
Sand 8%
Polystyrene 2%

 wall panel making machine production line

No. Name Function Size (mm) Power(KW) Quantity(set)
1 Slurry mixer Mixing cement mortar of up and own materials 2300×820×820 3 2
2 Main mixer Mixing middle materials 2800×1500×1300 18.5 2
3 Crusher Crush and collection material after cutting 1960×880×1070 11 1
4 Duplex units feed in mould board Automatic feed-in mould board on the main formed units, no need by manual, can reduce labor, improve work speed. 4800×3100×2800 1.5 1
5 Main formed units It includes all of device of automatic feed-in cement mortar, fiber cloth, spreading, one-time forming and etc. 29000×1800×1500 11.5 1
6 oil brusher It can adhibit the PVC paper on the mould board by automatic. (Or brush the oil on the mould board) 2700×1600×800 1.1 1
7 Automatic tracking cutting device It can cut the product on production line when it’s wet, and it will not hurt the product and mould board, reduce the labor, low labor intensity . 4500×2000×1450 2.45 1
8 Hydraulic lifter of receiving board system It can load the formed board on the form rack, reduce labor, reduce hurting the board when by manual, and improve automatic. 2700×3800×1700 9.6 1
9 PLC Control system Control the production line automatic. 750×500×1800   1

Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift 1Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift 2Decorative Magnesium Oxide Board Production Line Capacity 2000 Sheets / Shift 3
