Product Details:
|
| Features: | High Speed | Quality: | Good |
|---|---|---|---|
| Color: | Demand | Raw Materials: | Cement,sand,coal Ash,insulation Materials,etc |
| Application: | Wall Panel Making Machine | Size: | Standard |
| High Light: | eps sandwich panel production line,roof panel roll forming machine |
||
Concrete Panel / Eps Sandwich Mgo Wall Sheet Making Machine With High Speed
1. length of the production line:38000mm × 2200mm × 2800mm
2. Total Weight: about 24000KG
3. Main Power: 35KW
4. Working Speed: 4m/min
5. Material : 45# steel, quenched HRC 58-62
6. Electric Standard: 380V / 50 HZ / 3 PHASE
7. Feeding Width: 1150mm /1200m
8. Effective Width: 950mm
9. Thickness of the coil: 0.3-0.8mm
10. Density of EPS:18KG/M3
11. Output: 600,000m2 per year
12. Thickness of the material:0.4-0.8mm
13. Width of Material:1200mm Max
14. Core Material:EPS Board
15. Production line speed:3-5m/min
16. Production width:1000mm/960mm
17. Production thickness:50mm-150mm
18. EPS Sandwich panel machine is made up of color of tiles and core of EPS
19. Application: Public construction, roof and wall of workshop, building, both etc
20. Function:wall panel ,roof panel
21. Characteristic:quick construction ,everlasting,beautiful
|
|||||||||||
1. High capacity
Normal hollow core wall panel machine can make only ten panels in one mould, but this machine can make 15 panels at one time.
2. Lower the cost of production
2.1 We use stainless steel for the mould instead of traditional steel. Steel mould machines need brushing de-molding agent or the panels can't be taken out. Stainless steel machines don't need de-molding agent, this can save both labor and material cost for manufacturers. It can save around 0.1 USD per square meter.
3. The product quality is better.
Panels made by this kind of machine have better quality than other kinds. The panel will not be deformed. Its surface is smoother than others.
4. Hydraulic mould closing and opening
| Q | How many projects have you installed? |
| A | we have installed over 100projects in domestic and abroad. |
| Q | How many years experience do you have in mgo field? |
| A | Our general engineer has around 20years experience; all others have over 10years experience. |
| Q: | Do you supply spare parts? |
| A: | Excellent easy broken parts support for buyers. Easy broken parts guarantee for one year. |
| Q: | Will you provide trainning? |
| A: | The training is free of charge , and our engineer will be on duty to train your worker. |
| Q: | How will you provide installation&commissioning? |
| A: | Will provide 2~4persons(adjustable according to the degree of automatic )for installation. |
