|Product Name:||Building Moulding Board Machine||Production Capacity:||1500 Sheets|
|Texture Of Material:||Steel||Warranty:||1 Years|
|Automatic Grade:||Automatic||Raw Material:||Mgo,mgcl,fiber Glass Mesh|
Wall Panel Roll Forming Machine,
roll forming equipment
Fireproof Wheat Straw Wall Panel Equipment for Indoor Decoration / Building Material
newest fully Automatic Fireproof Wheat Straw Board production line
I. Usage and Technical Index of Product
The straw door is made of filling materials, such as sawdust and all kinds of crushed plant straw
(you can select any one kind ) and several chemical raw materials which are token as modified
material after special technology. The board has such features: quickly hard, high strength, large
format, fireproofing, dampproof and good waterproof performance. It can be nailed, planed and sticked,
so it can be used widely at indoor decoration, such as wall skirting and ceiling of market, hotel, club,
station, office building and living room. And it can get large usage at top-grade furniture, door and
partition. This product is made of waste materials, and it is ideal product which can replace all kinds
of wood broad with reasonable price and good quality.
1. Oxygenic index%: ＞90
2. Level combustion: SO
3. Vertical combustion: SO
4. Water content rate: 10.9%
5. Capacity: 1.15g/cm3
6. Static bending intensity: 169.46Mpa
7. Density: T/ m3 1.13
8. Water resistance: Without chalking for 24 hours and there is no change on surface
9. No “Three-wastes” (waste water, waste gas and waste residue), no pollution and environmental protection
II. Features of Production Line for New Type Luxurious Straw door
1. Structure principle and specification
Production line for straw door with fashionable design, reasonable structure, stable running
manufactured board of even thickness in large production once through double- roller-extruding technology. This production line is equipped with shaking device which remove inside and
outside air bubble, so our board is more compact. In addition, we use the no-woven cloth as the
separating film to increase the toughness and strength of the board. The machine can be adjusted
arbitrarily, and then produce the board with the thickness of 2-60mm, the biggest width of 1, 300mm
and unlimited length. So you can adjust the thickness of board at will.
2. The one machine can manufacture several boards
The machine can produce all kinds of products, such as simulated manchurian ash board, simulated
beech board, oak board, fireproof raised door board, skirting board, ceiling board and wall decorating
(1) Simulated wooden board: After state-level testing, its appearance is the same as that of the wooden
board, and its decorating effect, performance and performance-to-price ratio are all better than the same board. With a large breadth, it not only has the features which
the wooden board owns, such as nailed, sawed, planed and sticked, but also don’t need painting, so
it is green environment-friendly. For example: simulated beech board, red (black) walnut board and bubinga (Canthor).
(2) Fireproofing raised door: After province-level testing, it has such features: fireproofing,
waterproofness, sound insulation, heat preservation, variety and low cost.
(3) Wall decorating mural painting: The board produced by the board-making machine can be made into various decorating art mural painting about landscape, flower-and-bird, insect-and-fish as well as character. The product gets popularity from customers with excellent quality and
(4) Vent-pipe: The polystyrene sandwich panel produced by this machine can be made into the
vent-pipe used by the central air-conditioning system and all kinds of ventilation facility, and the
product is fireproof, dampproof, antiseptic, light-quality, heat-preservation, long-performance life and low-price. In view of the above features, it wins
much favor from users.
(5) Building moulding board: The strengthen moulding plate with this technology can replace steel
moulding board, bamboo & wood moulding board and multilayer board. Being a high-profit product, this
board is applied widely in all kinds of concrete engineering with low-cost, high strength, long life and
easy operation. The board is high-profit product.
In addition, in view of unique effect and great profit, various raised board with flower pattern and glazed
pantile can replace carved wall board about wallpaper and wall cloth.
If you want to get successful career, please grasp the business opportunity at any time……
III. Benefit Analysis
(I) Cost accounting
Raw material cost: 15 Yuan/ Piece; Wage: 0.5Yuan/ Piece; Water-electricity fee: 0.2 Yuan/ Piece; Depreciation of the workshop: 0.2Yuan/ Piece; Total: 15.90 Yuan/ Piece
(II) Profit analysis: production: (Take the middle-scale equipment as example),400 pieces per day, at
the common price of 40 Yuan/ Piece to sell, and
then the profit per piece is that: 40 Yuan/ Piece－15.9 Yuan/ Piece＝24.1 Yuan/ Piece, the profit per day is that: 400 pieces×24.1 Yuan/ Piece＝9640Yuan
IV. Production Conditions
The production line for straw door is composed of board-making machine, glue spreading-overlaying-drying machine and mat coating machine. According to the production and the automatization degree,
this production line is divided into 6 models and three specifications, such as large, middle and small
specification. The customer can select any kind, and we can manufacture the products according to
your special requirements. In addition, there are automatic cutting machine and mixing machine for
The production line for straw door has: production workshop, finished product workshop and raw
material warehouse. Workshop: 100---1000m2, worker: 3-6 person; fresh water; electricity:1.1-10KW
(According to different scale).
1. The Technology transfer fees of the composite straw door: 6000 Yuan (If you purchase our equipment,
then the technology fees is free. )
2. Sign the contract printed by Industry and Commerce Bureau.
3. We provide state-level certification about key new product, quality and fireproofing grade, and train
2-3 technical personnel for you till then they grasp the relevant technology.
4. There are production workshop, the relevant products, furniture and decorated room in company
for your visit. If you purchase large-scale equipment, we can install and test it in your company, then
ensure you can manufacture qualified product.
After purchased the equipment, our company will take responsibility for trainning technical personnel
until he can get the skill.
There are many professional technical personnel in our company, they will offer consultation about the
equipment and technology as well as technical training on site for free. And they will go to your factory
for installation and testing for free.
Welcome you to our company for a site visit, we will service for you sincerely.
Contact Person: Kevin
