Flow on Fiber Cement Board Production Line with Steel Texture Material

Flow on Fiber Cement Board Production Line with Steel Texture Material
Flow on Fiber Cement Board Production Line with Steel Texture Material Flow on Fiber Cement Board Production Line with Steel Texture Material Flow on Fiber Cement Board Production Line with Steel Texture Material Flow on Fiber Cement Board Production Line with Steel Texture Material

Large Image :  Flow on Fiber Cement Board Production Line with Steel Texture Material

Product Details:
Place of Origin: CHINA
Brand Name: chuangxin
Certification: CE
Model Number: XD-1
Payment & Shipping Terms:
Minimum Order Quantity: 10 sets
Price: 30000USD
Packaging Details: wood packing
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 10 set per month

Flow on Fiber Cement Board Production Line with Steel Texture Material

Description
Texture Of Materia: Steel Production Capacity: 1500 Sheets
Automatic Grade: Automatic Function: Fiber Cement Board
High Light:

fiber cement board machine

,

sheet forming machine

Flow on Fiber Cement Board Production Line with Steel Texture Material

1 million square meters flow-on fiber cement board production line
Product capacity:2-5 million square meters per year
Produc size:1220*2440mm,max length 4000mm.Thickness:4-100mm
Equipment list
A. Cellouse prepartion equipment
B. Cellouse storage system
C. Pulp production systerm'
D. Sheet Prduction system
E. Sheet transport system
F. Hydraulic vacuum stackinng machine, 3 working position
G. Hydraulic vacuum stackinng machine, 3 working position
H. Lifting platform
I. Templates oiling preparation
J. Templates stacker, two position
K. Press machine
L. Automatic roller transport system
M. Automatic roller transmission
N. Automatic cross transfer car track
O. Bottom plate
P. Gate overhead Crane
Q. Curng room
R. Single face sander
S. Edding and chamfering machine
T. Dust remover
1 Bending degrees
Horizontal > =22Mpa 24.9Mpa Qualified
Vertical > =17 Mpa 21.4Mpa
2  Impact strength > =2.0 KJ/m2 3.7KJ/m2 Qualified
3  Indensity > =1.6g/cm3 1.72g/cm3 Qualified
4  Water absorption < =24% 16.8% Qualified
5  Waterproofness According to the National standard GB8041 tested -24H checking allow damp mark on the back of the board, but no water drop Meet the National standard GB8041 Qualified
6  Freezing resistance According to the National standard GB8041 tested- after 25 times Cycliccrackingno break and layer appear Meet the National standard GB804
Compressive Strength~20 MPa (3, 000 PSI)
Impact Resistance> 6 kJ/m2
Tensile Strength> 5.5 MPa
Density (Specific Mass)~1000 Kg/m3 (+/-< 2%)
Moisture Absorption~26% maximum saturation (slow absorption rate)
Moisture Content~6%
Water Vapour Diffusion~28 / 35
Specific Heat~930 J/kgK
Thermal Conductivity~0.44 W / mK
Modulus of elasticity~6045 N/mm2
Flexibility
UNI E 12372
~20.1 N/mm2 maximum
12mm x 1220 x 2440 = 10 N/mm2
Surface Alkalinity~10 Ph
Thermal Expansion Hot/Cold0, 01 mm/mC (from temp +20C to -20C)
Expansion in Waterless than < 0.02% from ambient to saturation
Freeze / Thaw - UNI EN 520100 cycles without notable effects
Frost Resistanceno water drops form on surface
Combustibility / Fire Ratingsnon-combustible / 12mm exceeds 1 hr fire rating
Dimensional tolerancethick 0.2mm / width 2mm / length 3mm / Sq. 3mm
Toxicity Pollutants Heavy Metals - UNI EN 12457-2Below measurable levels of test instruments
Asbestos AnalysisAbsent - not measurable
Formaldehyde AnalysisAbsent - not measurable
Sound Attenuation (9mm)tested design ASTM E90 = STC 48, 50, 55, & 60
ColorSlate Grey and Chalk White
Surface texturesmooth one side; uniform machine textured back
Basic Compounds(MgO)+(natural silicates)+(glass fibre)+(wood fibre)

         Flow on Fiber Cement Board Production Line with Steel Texture Material 0Flow on Fiber Cement Board Production Line with Steel Texture Material 1
