Product Details:
|
| Product Name: | Building Moulding Board Machine | Texture Of Material: | Steel |
|---|---|---|---|
| Warranty: | 1 Years | Automatic Grade: | Automatic |
| Raw Material: | Mgo,mgcl,fiber Glass Mesh | Standard: | CE |
| Type: | Free Standing | Main Process: | Forming |
| Application: | Wall | Place Of Origin: | Shandong China |
| High Light: | roll forming machinery,lightweight wall panel machine |
||
1) Wide raw material resource
mgomglsawduststraw and so on.
2) Easy process technology
adopt the technology of two-drive two-rollar-excuding
3) Skillful installation engineer
Usage and Technical Index of Product
1. Composition:
Core Material: EPS, Cement and fly ash core.
Surface materials: Fiber reinforced Calcium silicone board or Cement Calcium Silicone Board.
2. Specification:
L*W*T: 2440mm*610mm*50mm/60mm/75mm/90mm/100mm/120mm/150mm.
2270mm* 610mm*50mm/60mm/75mm/90mm/100mm/120mm/150mm/180mm.
3. Application:
Interior and exterior partition on steel or concrete structure building.
For New Construction, Additions,or Renovations.
4.Special Features:
Different Wall Thickness: 60mm, 75mm, 90mm,100mm, 120mm, 150mm,180mm.
Maximum width: 610mm.
Length: According to your demands, engineering requirements, and shipment conditions.
5. Advantages:
· Light weight
· Good sound insulateds
· Heat Insulated
· Waterproof/ Water fast : Near about 0% moisture absorption.
· Fire proof.
· Energy Efficient
· Environmental, Ecofriendly.
· Civilized and convenient construction
· High Intensity without deformation.
Technology index
| serial number | Inspection items |
Standard requirement (thickness 8mm) |
inspection results | |
| 1 | Flexural strength | >8.0 | 10.3 | |
| 2 | Impact strength | >1.5 | 4.84 | |
| 3 | performance density | 0.7<p<1.0 | 0.92 | |
| 4 | Back to halogen resistance | No water, no get damp | No water, no get damp | |
| 5 | Dry shrinkage | <0.3 | 0.21 | |
| 6 | Wet bilge rate | <0.6 | 0.40 | |
| 7 | With screw force | >15 | 61 | |
| 8 | The chloride ion content | <10 | 2.96 | |
| 9 | The factory of moisture content | <8 | 7.5 | |
| 10 | incombustible | The average temperature in the furnace |
<50 |
8 |
| The average combustion duration |
<20 |
0 |
||
| The average mass loss rate |
<50 |
47.5 |
||
Main equipment list:
|
Item |
Equipment name |
|
Dosage control system |
Automatic batch turning system Microcomputer control system Dust collection system Elevating conveying system Automatic measure system Shell fabric mixing system Middle material mixing system Pulp stock mixing system Accessories dressing by screen system Blending agent dessolving system Blending agen dessolving and automatic measurement system |
|
Forming system |
Vaccum compressed air control system Automatic mould system Forming conveying system Rolling forming system Automatic cutting board system Automatic collecting board twinlift system Computer touching control system Speedup rod road Loading vehicle changing tracksystem |
|
Curing system |
Constant temperature system in curing room Curing room automatic humidity controlled system Automatic stripping system Automatic stacking board system Forklift |
|
Arranging board system |
Rod road conveying system Horizontal and perpendcular high speed cutting machine Landscape orientation conveyor Sanding machine Dust colletion system Microcomputer self-control system Power distributing system |
